Specifications

Operating System

Windows 8.1 or android

Processor

Intel Bay Trail-T CR Z3735F, Cores 4, Threads 4

Processor Base Frequency: 1.33GHz

Burst Frequency: 1.83GHz

Scenario Design Power(SDP) 2.2W

Memory

DDR3L 2GB

SSD

eMMC 64GB

Extension

Micro SD up to 128GB

I/O

1 × Display port

1 × HDMI

4 x USB 2.0

1 x RJ45

1 x Micro SD

1 x 3.5mm Stereo Jack

1 x 3.5mm MIC

1 x DC Jack(5V-2.5A)

Wifi/Bluetooth

WIFI:802.11 b/g/n

Bluetooth:4.0

Power Adapter

Input: AC100-240~50/60hz 0.5A MAX

Output: 5.0V-2.5A

Size

107 x 107 x 25 mm

Weight

250 gr

Video encoding format

Video (H264,H263,mpeg4,vp8,vp9)

File Type (*.3gp, *.mp4, *.ts, *.mkv, *.avi)

Audio encoding format

Audio code(aac, amrnb, amrwb, g711-alaw, g711-mlaw, mp3, vorbis, alac, raw, flac, gsm)

File Type(*.mp3, *.wav, *.ogg, *.flac, *.mid, *.amr, *.aac, *.ts, *.mp4, *.m4a, *.3gp, *.mkv)

Image Format

PNG, GIF, BMP

Video

Support 30 FPS full 1080p HD format video playback
